One of the activities of the ByTechService company is supply and installation of electronic cashiers with recirculation function (TCR).

CIMA AST 7008

---

electronic
cashier
recirculator

electronic cashier CIMA AST 7000
country of production: ITALY

CIMA AST 7000 (Italy) It is designed for use in workplaces with a large number of transactions, guarantees security and reliability, and also provides high speed of customer service.

The unique technology of “direct and continuous banknote feeding”, developed and patented by CIMA (Italy), which deliver banknotes directly to the desired drum without changing their direction of movement in the recirculator, allows the device to work without jams and choking of banknotes.

In addition, this technology provides for the cancellation of the operation, immediate return to the client of his/her own banknotes, regardless of their number in the received deposit.

• Dimensions: 440 (width) х 860 (depth) х 670 (height) mm
• Safe: UL291 (CEN L, CEN lll and CEN IV options).
• Power supply: 220 V, 50 Hertz.
• Power consumption: 600 W.
• Interface: Serial port RS232, USB 1.0. port or Ethernet.
• Validator: CIMA Bv5000.
• Electronic lock: LG L4133/39E.
• Number of drums: 8.
• Capacity of each drum: 700 banknotes.
• Speed of acceptance and dispensing of banknotes: 7 banknotes per second.
• Warranty: 12 months.
• Weight from 160 to 480 kg.

1. The device is equipped with 8 reels up to 700 banknotes each.
2. Application of the production recognition module Giesecke&Devrient allows to guarantee high quality of checking banknotes and work with different currencies.

3. Due to small dimensions and ergonomic design, the electronic cashier CIMA AST 7000 can be installed in any workplace and harmoniously fit into the interior of the bank.

4. TCR AST 7000 produces reception and delivery of money resources with speed 7 banknotes per second.

5. Modular design allows servicing the device if necessary. The module can be removed from the recirculation housing.

Electronic cashier ClMA AST 7000 7000 successfully passed testing in banks of the CIS countries.

ClMA AST 7000 carries out the storage of banknotes in a safe; it is possible to install safes with a degree of protection from burglary from zero to lll class

APPLICATION CLMA AST 7000 PROVIDES THE FOLLOWING ADVANTAGES:

• Significant reduction of customer service time for the operation of receiving and issuing banknotes.
• A different type of safe allows you to select a device with an acceptable level of security.
• The balance of a device in real time.
• Improved productivity and customer service.
• Reducing the risks of human factor influence when working with cash.
• Ability to return banknotes of the client in case of his/her refusal to perform the operation.
• Decrease in the volume of funds in the unprotected space of the office.
• Comfortable maintenance which does not require much space.
• Easy integration into ABS.

electronic cashier recirculator (TCR) and device for depositing CIMA AST 7008
country of production: ITALY

CIMA AST 7008 is a unique device that successfully combines an electronic cashier-recirculator (TCR) and a device for depositing (CDS). This is the best solution for organizing services for legal entities, retailers, as well as for back-offices of banks.

CIMA AST 7008 Easy to modify to your current requirements.

Device features CIMA AST 7008:

• The technology of "direct and continuous supply of banknotes" allows you to work without jams and jamming banknotes.
• Upon cancellation of the operation, immediate return to the customer of his own banknotes, regardless of their quantity in the accepted deposit.
• Integration with devices for receiving and issuing coins is possible.
• Ability to work with multiple currencies simultaneously.
• To automate the collection of banknotes located on the reels, can automatically be sent to the bag.
• A different embodiment of safes allows you to provide the required level of security.

• Recycling 8 reels, up to 700 banknotes each.
• Deposit module, up to 10,000 banknotes.
• Safe: 12 mm (UL 291), CEN L, CEN III.
• Interface: RS 232 / USB 1.0 / Ethernet port.
• Bag capacity:
• reusable bag for 10,000 banknotes;
• stacking in a disposable bag with a capacity of up to 3,000 banknotes.
• Validator CIMA BV5000.
• Banknote reception and delivery rate: up to 6 per second.
• Power supply: 220 V, 50 Hz.

AST 7008 H - 8 recycling reels up to 700 banknotes each + WinWin Heat Bag.
AST 7008 HB - 8 recycling reels up to 700 banknotes each + WinWin Heat Bag + tape packaging module.
AST 7008 S - 8 recycling reels up to 700 banknotes each + WinWin Stacing Bag (stacking banknotes in a stack).
AST 7008 С - 8 recycling reels up to 700 banknotes each + reusable bag for 10,000 banknotes.
AST 7008 CB - 8 recycling reels up to 700 banknotes each + reusable bag for 10,000 banknotes + tape packaging module.

ClMA AST 7008 carries out storage of banknotes in a safe; safes can be installed with a degree of protection against hacking from zero to lll class

• The device is equipped with 8 reels with a capacity of up to 700 banknotes each.
• The use of the recognition module allows you to guarantee high quality banknote verification and work with various currencies.
• The device balance is available in real time.
• The modular design allows you to make device maintenance comfortable.
• The ability to connect the device to a burglar alarm.
